| 1 |
85211081AN
|
SHIM TH. 1,3
|
€
1.45
|
|
|
| 1 |
85211081AL
|
SHIM TH. 1,1
|
€
6.21
|
|
|
| 1 |
025147054
|
THRUST WASHER 25.2X32.5X1.2
|
€
0.77
|
|
|
| 1 |
85211081AH
|
SHIM TH. 0.9
|
€
0.84
|
|
|
| 1 |
025147050
|
THRUST WASHER 25.2X32.5X1
|
€
0.61
|
|
|
| 2 |
15020061A
|
MAIN SHAFT T15
|
€
375.23
|
|
|
| 3 |
067016150
|
THRUST WASHER 0.5 MM
|
€
0.50
|
|
|
| 4 |
70140051A
|
BEARING, NEEDLE
|
€
8.04
|
|
|
| 5 |
17210041A
|
GEAR, INPUT 5TH, 24T
|
€
79.90
|
|
|
| 6 |
85610011A
|
THRUST WASHER 0.5 MM
|
€
0.90
|
|
|
| 7 |
067016145
|
SPRING RING
|
€
0.52
|
|
|
| 8 |
17210031A
|
GEAR DRIVE 3/4TH SPEED T20/22
|
€
144.81
|
|
|
| 9 |
17210051A
|
GEAR, 6TH DRIVE NT:28
|
€
45.92
|
|
|
| 10 |
17210021B
|
GEAR, 2ND DRIVE, NT:17
|
€
63.43
|
|
|
| 11 |
71310141B
|
SHIM TH. 1.7
|
€
3.18
|
|
|
| 11 |
71310141E
|
THRUST WASHER 20.3X32X1.6
|
€
0.50
|
|
|
| 11 |
067016164
|
THRUST WASHER 20.3X32X2
|
€
3.09
|
|
|
| 11 |
067016163
|
THRUST WASHER 20.3X32X1.8
|
€
18.39
|
|
|
| 11 |
71310141A
|
THRUST WASHER 20.3X32X1.5
|
€
1.20
|
|
|
| 11 |
71310141F
|
SHIM TH. 1.9
|
€
3.50
|
|
|
| 12 |
44910531A
|
SPROCKET T15
|
€
26.89
|
|
|
| 13 |
71312041A
|
SPACER
|
€
10.75
|
|
|
| 14 |
93040231A
|
O-RING
|
€
0.50
|
|
|
| 15 |
067016165
|
THRUST WASHER 20.3X32X2.2
|
€
2.86
|
|
|
| 15 |
71310111A
|
WASHER, THRUST 17.2X32X2.3
|
€
11.27
|
|
|
| 15 |
71310141A
|
THRUST WASHER 20.3X32X1.5
|
€
1.20
|
|
|
| 15 |
067016184
|
WASHER, THRUST 17.2X32X1
|
€
2.64
|
|
|
| 15 |
067016164
|
THRUST WASHER 20.3X32X2
|
€
3.09
|
|
|
| 15 |
71310141E
|
THRUST WASHER 20.3X32X1.6
|
€
0.50
|
|
|
| 15 |
067016185
|
WASHER, THRUST 17.2X32X1.2
|
€
3.85
|
|
|
| 16 |
85610311A
|
THRUST WASHER 0.5 MM
|
€
1.52
|
|
|
| 17 |
764020002
|
BEARING, NEEDLE
|
€
9.58
|
|
|
| 18 |
17210061B
|
DRIVEN GEAR 1ST SPEED T37
|
€
121.75
|
|
|
| 19 |
067016155
|
THRUST WASHER 1 MM
|
€
1.20
|
|
|
| 20 |
17210101A
|
DRIVEN GEAR 5TH SPEED 23T
|
€
116.82
|
|
|
| 21 |
17210091A
|
DRIVEN GEAR 4TH SPEED T:24
|
€
63.00
|
|
|
| 22 |
17210081A
|
DRIVEN GEAR 3RD SPEED T27
|
€
101.33
|
|
|
| 23 |
17210111A
|
DRIVEN GEAR 6TH SPEEDT:24
|
€
125.89
|
|
|
| 24 |
17212192A
|
DRIVEN GEAR 2ND SPEED T30
|
€
119.01
|
|
|
| 25 |
14910323A
|
GEARBOX LAY SHAFT
|
€
262.77
|
|
|
| 26 |
067016170
|
THRUST WASHER 0.8 MM
|
€
0.77
|
|
|
| 26 |
85211051AG
|
SHIM TH. 0.7
|
€
0.84
|
|
|
| 26 |
067016171
|
THRUST WASHER 1.0 MM
|
€
0.94
|
|
|
| 26 |
85211051AD
|
SHIM TH. 1,1
|
€
0.85
|
|
|
| 26 |
85211051AB
|
SHIM TH. 0.9
|
€
0.73
|
|
|
| 27 |
15020051A
|
COMPLETE MAIN SHAFT
|
€
675.16
|
|
|
| 28 |
15020631A
|
GEARBOX LAY SHAFT
|
€
891.90
|
|
|
| 29 |
70250441A
|
NEEDLE BEARING
|
€
2.68
|
|
|
| 30 |
93040491A
|
SEAL RING
|
€
16.28
|
|
|
| 31 |
85110041A
|
WASHER, LOCK
|
€
1.15
|
|
|
| 32 |
75010071A
|
NUT M25X1.5
|
€
11.70
|
|
|
