| 1 |
59521071A
|
SEAT
|
|
€
178.96
|
|
|
| 2 |
86610201A
|
RUBBER PAD
|
|
€
1.96
|
|
|
| 3 |
86610301A
|
PAD
|
|
€
1.96
|
|
|
| 4 |
85212181A
|
WASHER, NYLON 9X14X1
|
|
€
0.93
|
|
|
| 5 |
77210842A
|
SPECIAL SCREW
|
|
€
2.99
|
|
|
| 6 |
77210851B
|
SPECIAL SCREW
|
|
€
2.99
|
|
|
| 7 |
77210861B
|
SCREW TBEI M5X18
|
|
€
1.96
|
|
|
| 8 |
88440251A
|
CIRCLIP
|
|
€
0.93
|
|
|
| 9 |
85040821A
|
THREADED INSERT WELLNUT M5X0.8X16
|
|
€
1.96
|
|
|
| 10 |
4713071AB
|
COVER SEAT (MIDNIGHT BLACK)
|
|
€
0.00
|
|
|
| 10 |
4713071AA
|
COVER SEAT (RED)
|
|
€
0.00
|
|
|
| 11 |
59510911A
|
PAD,SEAT
|
|
€
41.51
|
|
|
| 12 |
8321551AB
|
TAIL GUARD (MIDNIGHT BLACK)
|
|
€
0.00
|
|
|
| 12 |
8321551AA
|
TAIL GUARD (RED)
|
|
€
0.00
|
|
|
| 13 |
46012591A
|
NET FRONT LH
|
|
€
16.40
|
|
|
| 14 |
46012601A
|
NET FRONT RH
|
|
€
16.40
|
|
|
| 15 |
46012612A
|
NET REAR LH
|
|
€
28.76
|
|
|
| 16 |
59521031A
|
PILLION RIDER SEAT
|
|
€
137.15
|
|
|
| 17 |
46012461A
|
PROTECTOR HEAT REAR COWLING
|
|
€
113.75
|
|
|
| 18 |
46012622A
|
NET REAR RH
|
|
€
28.76
|
|
|
| 19 |
43814361A
|
STICKER "DUCATI" (L.H.) (FOR RED)
|
|
€
5.77
|
|
|
| 19 |
3814361AT
|
STICKER "DUCATI" (L.H.) (FOR MIDNIGHT BLACK)
|
|
€
0.00
|
|
|
| 20 |
77914992A
|
SPECIAL SCREW
|
|
€
1.96
|
|
|
| 21 |
59820541A
|
kit serrature
|
|
€
0.00
|
|
|
| 22 |
59820231A
|
SEAT LOCK
|
|
€
49.21
|
|
|
| 23 |
83014251A
|
HOOK
|
|
€
12.11
|
|
|
| 24 |
74940041A
|
NUT, SELF-LOCKING M6
|
|
€
0.93
|
|
|
| 25 |
76410541A
|
RUBBER PAD
|
|
€
5.05
|
|
|
| 26 |
79911751A
|
SPRING
|
|
€
2.99
|
|
|
| 27 |
84110371A
|
RETAINER
|
|
€
5.05
|
|
|
| 28 |
85044691A
|
QUICK FASTENING
|
|
€
1.96
|
|
|
| 29 |
91371191C
|
OWNER'S MANUAL
|
E |
€
26.56
|
|
|
| 29 |
91371191B
|
OWNER'S MANUAL
|
E |
€
26.56
|
|
|
| 29 |
91371191D
|
OWNER'S MANUAL
|
F |
€
26.56
|
|
|
| 29 |
91371191A
|
OWNER'S MANUAL
|
I |
€
25.79
|
|
|
| 30 |
48211841A
|
COVER FRAME LH
|
|
€
53.09
|
|
|
| 31 |
48211851A
|
COVER FRAME RH
|
|
€
53.09
|
|
|
| 32 |
43814391A
|
STICKER "DUCATI" (R.H.) (FOR RED)
|
|
€
5.77
|
|
|
| 32 |
3814391AT
|
STICKER "DUCATI" (R.H.) (FOR MIDNIGHT BLACK)
|
|
€
0.00
|
|
|
| 33 |
77914982A
|
SCREW TCPEI M6
|
|
€
4.02
|
|
|
| 34 |
59810111A
|
STRIKER SEAT LOCK
|
|
€
40.95
|
|
|
| 35 |
83014401A
|
BRACKET, SEAT LOCK
|
|
€
6.10
|
|
|
| 36 |
69720223A
|
TOOL BAG
|
|
€
14.50
|
|
|
| 37 |
85040381A
|
QUICK FASTENING
|
|
€
2.99
|
|
|
