| 1 |
59521071A
|
SEAT
|
€
178.96
|
|
|
| 2 |
86610191A
|
CUSHION, SEAT
|
€
1.96
|
|
|
| 3 |
86610301A
|
PAD
|
€
1.96
|
|
|
| 4 |
85212181A
|
WASHER, NYLON 9X14X1
|
€
0.93
|
|
|
| 5 |
77210842A
|
SPECIAL SCREW
|
€
2.99
|
|
|
| 6 |
77214411AA
|
SCREW BLACK
|
€
2.99
|
|
|
| 7 |
77210861B
|
SCREW TBEI M5X18
|
€
1.96
|
|
|
| 8 |
88440251A
|
CIRCLIP
|
€
0.93
|
|
|
| 9 |
85040821A
|
THREADED INSERT WELLNUT M5X0.8X16
|
€
1.96
|
|
|
| 10 |
24713071AA
|
COVER SEAT (RED)
|
€
149.49
|
|
|
| 10 |
24713071AB
|
COPERCHIO SELLA (MIDNIGHT BLACK)
|
€
149.49
|
|
|
| 10 |
24713071AW
|
COPERCHIO SELLA (BIANCO)
|
€
149.49
|
|
|
| 11 |
59510911A
|
PAD,SEAT
|
€
41.51
|
|
|
| 12 |
48320741AB
|
CODONE (MIDNIGHT BLACK)
|
€
621.84
|
|
|
| 12 |
48320741AA
|
TAIL GUARD (RED)
|
€
621.84
|
|
|
| 12 |
8320741AW
|
CODONE (BIANCO)
|
€
0.00
|
|
|
| 13 |
46012591A
|
NET FRONT LH
|
€
16.40
|
|
|
| 14 |
46012601A
|
NET FRONT RH
|
€
16.40
|
|
|
| 15 |
46012612A
|
NET REAR LH
|
€
28.76
|
|
|
| 16 |
59521031A
|
PILLION RIDER SEAT
|
€
137.15
|
|
|
| 17 |
46012461A
|
PROTECTOR HEAT REAR COWLING
|
€
113.75
|
|
|
| 18 |
46012622A
|
NET REAR RH
|
€
28.76
|
|
|
| 19 |
43810671AS
|
STICKER "DUCATI" (FOR RED)
|
€
11.64
|
|
|
| 19 |
43810671AT
|
DECALCOMANIA "DUCATI" (PER NERO/BIANCO)
|
€
11.64
|
|
|
| 20 |
77914992A
|
SPECIAL SCREW
|
€
1.96
|
|
|
| 21 |
59820541A
|
kit serrature
|
€
0.00
|
|
|
| 22 |
59820572A
|
SEAT LOCK
|
€
65.23
|
|
|
| 23 |
83014251A
|
HOOK
|
€
12.11
|
|
|
| 24 |
74940041A
|
NUT, SELF-LOCKING M6
|
€
0.93
|
|
|
| 25 |
76410541A
|
RUBBER PAD
|
€
5.05
|
|
|
| 26 |
79911751A
|
SPRING
|
€
2.99
|
|
|
| 27 |
84110371A
|
RETAINER
|
€
5.05
|
|
|
| 28 |
85044691A
|
QUICK FASTENING
|
€
1.96
|
|
|
| 29 |
91371391L
|
LIBRETTO USO E MANUTENZIONE
|
€
26.56
|
|
|
| 29 |
91371391M
|
LIBRETTO USO E MANUTENZIONE
|
€
26.56
|
|
|
| 29 |
91371391P
|
LIBRETTO USO E MANUTENZIONE
|
€
26.56
|
|
|
| 29 |
91371391N
|
LIBRETTO USO E MANUTENZIONE
|
€
26.56
|
|
|
| 30 |
48211841A
|
COVER FRAME LH
|
€
53.09
|
|
|
| 31 |
48211851A
|
COVER FRAME RH
|
€
53.09
|
|
|
| 32 |
69720223A
|
TOOL BAG
|
€
14.50
|
|
|
| 33 |
77914982A
|
SCREW TCPEI M6
|
€
4.02
|
|
|
| 34 |
59810111A
|
STRIKER SEAT LOCK
|
€
40.95
|
|
|
| 35 |
83014401A
|
BRACKET, SEAT LOCK
|
€
6.10
|
|
|
| 36 |
92610101A
|
PROTECTOR HEAT
|
€
12.77
|
|
|
| 37 |
92610061A
|
GUARD
|
€
6.81
|
|
|
| 38 |
74941108B
|
NUT, SELF-LOCKING M5X0.80 CH8
|
€
0.93
|
|
|
| 39 |
85540011A
|
SPRING WASHER
|
€
0.93
|
|
|
| 40 |
70010601A
|
VIBRATION DAMPER
|
€
10.78
|
|
|
| 41 |
77211041A
|
SCREW
|
€
2.99
|
|
|
| 42 |
85040381A
|
QUICK FASTENING
|
€
2.99
|
|
|
