| 1 |
77112331A
|
SCREW TCEI M6X16
|
1 |
€
0.90
|
|
|
| 2 |
14010701B
|
INTAKE MANIFOLD
|
2 |
€
46.02
|
|
|
| 3 |
85212971A
|
COPPER GASKET
|
3 |
€
0.90
|
|
|
| 4 |
81416941A
|
UNION
|
4 |
€
5.14
|
|
|
| 5 |
77253367C
|
SCREW
|
5 |
€
1.90
|
|
|
| 6 |
76610821A
|
STUD BOLT
|
6 |
€
0.90
|
|
|
| 7 |
78811102C
|
VALVE COVER GASKET EXTERNAL
|
7 |
€
13.16
|
|
|
| 8 |
78811131A
|
VALVE COVER GASKET INTERNAL
|
8 |
€
1.90
|
|
|
| 9 |
85212781B
|
WASHER
|
9 |
€
0.90
|
|
|
| 10 |
77919401A
|
SCREW
|
10 |
€
1.90
|
|
|
| 11 |
24715341B
|
COVER CYLINDER HEAD, HORIZONTAL
|
11 |
€
132.70
|
|
|
| 12 |
77253300ZF
|
SCREW
|
12 |
€
0.90
|
|
|
| 13 |
85611471A
|
PLATE, RETAINER
|
13 |
€
5.64
|
|
|
| 14 |
17111301A
|
GEAR 30T
|
14 |
€
97.38
|
|
|
| 15 |
77913541A
|
THREADED PLUG M15X1
|
15 |
€
13.77
|
|
|
| 16 |
85211201A
|
ALUMINIUM GASKET
|
16 |
€
1.90
|
|
|
| 17 |
86050061A
|
PIN M5X10
|
17 |
€
1.90
|
|
|
| 18 |
14815071A
|
HORIZONTAL INTAKE CAMSHAFT
|
18 |
€
511.03
|
|
|
| 19 |
14824211C
|
HORIZONTAL EXHAUST CAMSHAFT
|
19 |
€
511.03
|
|
|
| 20 |
82113832A
|
PIN
|
20 |
€
12.26
|
|
|
| 21 |
77919391A
|
SCREW, SPECIAL
|
21 |
€
5.31
|
|
|
| 22 |
79915534A
|
SPRING
|
22 |
€
6.76
|
|
|
| 23 |
30710021A
|
DECOMPRESSION DEVICE
|
23 |
€
39.45
|
|
|
| 24 |
85240231A
|
WASHER 8.2X14X0.5
|
24 |
€
0.90
|
|
|
| 25 |
74810791A
|
NUT
|
25 |
€
0.90
|
|
|
| 26 |
76640191A
|
STUD BOLT
|
26 |
€
0.90
|
|
|
| 27 |
77210621A
|
SCREW TEF M5X16
|
27 |
€
0.90
|
|
|
| 28 |
24714103AD
|
VALVE COVER HORIZONTAL
|
28 |
€
17.13
|
|
|
| 29 |
81140011C
|
REED VALVE ASSY
|
29 |
€
16.11
|
|
|
| 30 |
82716351A
|
PLATE
|
30 |
€
5.14
|
|
|
| 31 |
14824511C
|
HORIZONTAL EXHAUST CAMSHAFT (Unit)
|
31 |
€
511.03
|
|
|
| 32 |
86010061A
|
PIN
|
32 |
€
2.90
|
|
|
| 33 |
76610811A
|
STUD BOLT FASTENING HEAD CYLINDER
|
33 |
€
2.90
|
|
|
| 34 |
81413341A
|
UNION
|
34 |
€
7.86
|
|
|
| 35 |
85250231A
|
GASKET
|
35 |
€
0.90
|
|
|
| 36 |
74810461A
|
NUT, FLANGE M10X1
|
36 |
€
2.90
|
|
|
| 37 |
74840482A
|
NUT
|
37 |
€
0.90
|
|
|
| 38 |
85212771A
|
WASHER
|
38 |
€
0.90
|
|
|
| 39 |
85610642A
|
WASHER, SPECIAL 10.5X21X2
|
39 |
€
0.90
|
|
|
