| 1 |
74750071A
|
NUT
|
1 |
€
0.90
|
|
|
| 2 |
77850281A
|
THREADED DOWEL STEI M8X25
|
2 |
€
0.90
|
|
|
| 3 |
34220872AA
|
STEERING HEAD BASE (Unit)
|
3 |
€
311.59
|
|
|
| 4 |
77156688B
|
SCREW TCEIF M6X22X18
|
4 |
€
1.90
|
|
|
| 5 |
93010041B
|
OIL SEAL
|
5 |
€
5.32
|
|
|
| 6 |
70241232A
|
BEARING, CONICAL ROLLERS
|
6 |
€
40.80
|
|
|
| 7 |
75012341AA
|
SCREW, SPECIAL
|
7 |
€
3.90
|
|
|
| 7 |
87210641A
|
CAP, CONNECTOR
|
7 |
€
0.90
|
|
|
| 8 |
52310621A
|
REAR-VIEW MIRROR R.H.
|
8 |
€
171.35
|
|
|
| 9 |
52310631A
|
REAR-VIEW MIRROR L.H.
|
9 |
€
171.35
|
|
|
| 10 |
70011151A
|
CUSHION, HANDLEBAR
|
10 |
€
10.88
|
|
|
| 11 |
85211031AB
|
WASHER
|
11 |
€
2.90
|
|
|
| 12 |
70310441A
|
RING NUT
|
12 |
€
50.45
|
|
|
| 13 |
77157248B
|
SCREW TCEIF M8X22
|
13 |
€
1.90
|
|
|
| 14 |
65110221C
|
LEFT SWITCH
|
14 |
€
202.42
|
|
|
| 14 |
65110231C
|
LEFT SWITCH
|
14 |
€
196.80
|
|
|
| 15 |
71112791A
|
BUSH
|
15 |
€
8.37
|
|
|
| 16 |
36011971AA
|
HANDLEBAR
|
16 |
€
120.12
|
|
|
| 17 |
77157273BA
|
SCREW
|
17 |
€
4.90
|
|
|
| 18 |
7791A111AA
|
SCREW, SPECIAL
|
18 |
€
7.01
|
|
|
| 19 |
77113981AA
|
SCREW L.H.
|
19 |
€
4.90
|
|
|
| 20 |
66020102B
|
THROTTLE CONTROL (Unit)
|
20 |
€
196.92
|
|
|
| 21 |
15310072B
|
BALANCER SET, HANDLE BAR
|
21 |
€
10.98
|
|
|
| 22 |
46210021A
|
SPRING WASHER 8 MM
|
22 |
€
0.90
|
|
|
| 23 |
34111141AA
|
STEERING HEAD
|
23 |
€
267.95
|
|
|
| 24 |
36011852AA
|
HANDLEBAR BRACKET, UPPER LEFT
|
24 |
€
52.35
|
|
|
| 25 |
65010223A
|
RIGHT SWITCH
|
25 |
€
124.83
|
|
|
| 26 |
36011862AA
|
HANDLEBAR BRACKET, UPPER RIGHT
|
26 |
€
52.35
|
|
|
| 27 |
36011882AA
|
HANDLEBAR BRACKET, LOWER RH
|
27 |
€
92.50
|
|
|
| 28 |
77113941A
|
SCREW TCEIF M10X1.25X65 8.8
|
28 |
€
4.90
|
|
|
| 29 |
36011872AA
|
HANDLEBAR BRACKET, LOWER LH
|
29 |
€
92.50
|
|
|
| 30 |
59821621F
|
HANDS FREE 868 MHZ KIT
|
30 |
€
621.18
|
|
|
| 31 |
77150763B
|
SCREW TCEI M6X55 UNI5931 8.8
|
31 |
€
2.90
|
|
|
| 32 |
71011451A
|
BUSH
|
32 |
€
11.21
|
|
|
| 33 |
85250401A
|
WASHER 10.5X18X1.6
|
33 |
€
0.90
|
|
|
| 34 |
85210491B
|
WASHER 10.5X28X1.5
|
34 |
€
5.10
|
|
|
| 35 |
38510821B
|
SWITCH HANDS FREE 868 MHZ
|
35 |
€
405.06
|
|
|
| 36 |
7715727BF
|
SCREW
|
36 |
€
2.90
|
|
|
| 37 |
71614914AA
|
SPACER
|
37 |
€
5.07
|
|
|
| 38 |
24715521A
|
COVER HANDSFREE
|
38 |
€
6.67
|
|
|
| 39 |
75011491A
|
NUT
|
39 |
€
5.31
|
|
|
| 40 |
83040071A
|
CLIP
|
40 |
€
1.90
|
|
|
| 41 |
82113291B
|
PIN
|
41 |
€
10.64
|
|
|
| 42 |
87211071A
|
COVER
|
42 |
€
27.27
|
|
|
